Our HG Precision Punches for kinds of press are made from high nickel, high chrome shock steel. Among the many factors that go into steel selection for us to manufacture Stamping Tooling Punch, Punch Pin, Punch&Die, chemical atmosphere, abrasive nature of the product, turret speed, cup depth, location of embossing, bisect land and physical condition of the press. We also offer custom punch die sets on demand.

There are many types of coatings and treatments available that can be applied to tool steel to enhance stamping tooling  punch& other components for metal stamping..

1 ] Round Shape Punch Die Sets

These punch die sets help you to produce round shape tablets. Normally round shapes punch die sets used by pharmaceutical and veterinary industry. These punch die sets are available with different size, concavity, and flat in plain or engraved break line.

By using round shape punch die sets you can also manufacture following types of tablet :

2 ] Capsule Shape Punch Die Sets

It helps you to produce capsule shape tablets. Capsule shape punch die sets applicable to pharmaceutical and ayurvedic industries. These punch die sets are available with different size, concavity, and flat in plain or engraved break line.

By using capsule shape punch die sets, you can manufacture following types of tablet :

• Concave with Edges
• Deep Concave
• Flat Faced
• Normal concave
• Flat with Bevel Edges

3 ] Oval Shape Punch Die Sets

It helps you to produce oval / ellipse shape tablets. Normally oval shape punch die sets are applicable to pharmaceutical and ayurvedic industries. These punch die sets are available with different size, concavity, and flat in plain or engraved break line.

By using oval shape punch die sets, you can manufacture following types of tablet :

• Flat Faced
• Flat with bevel edges
• Concave/Deep/Deep
• Concave with bevel edges

4 ] Geometric Shape Punch Die Sets

It helps you to produce tablets with different geometric shapes like square, rectangular, triangular, benzine, rohmbus etc. Normally shaped (regular) punch die sets are applicable to pharmaceutical, confectionery, chemical, industrial powder metallurgy industries. These punch die sets are available with different size, concavity, and flat in plain or engraved break line.

By using geometric shape punch die sets, you can manufacture following types of tablet :

• Triangular
• Benzine
• Rohmbus
• Rectangular
• Square

Irregular Shape Punch Die Sets

• [Animal,      Diamond, Special Shape]

       Irregular shape tablet punch die sets with animal, diamond, and special shape are available.

Irregular shape punch die sets produce tablets with different shapes like fruit, animals, part of human body, vehicle etc. Normally irregular shape punch die sets are applicable to confectionery industries. These punch die sets are available with different size, concavity, and flat in plain or engraved break line.

We manufacture core rod toolings punch die sets that produce tablets having hole in center.

Core rod toolings punch die sets produce tablets having hole in center. Normally core rod toolings punch die sets are applicable in confectionery and ceramic industries. These punch die sets are available with different size, concavity, and flat in plain or engraved break line.

By using core rod toolings punch die sets, you can manufacture following types of tablet:
• Tablet with hole in center & concave rib
• Tablet with hole in center & flat rib

 Sealed Grove Punch Die Sets

We also manufacture sealed grove punch die sets.

Granule contamination during the tabletting process can cause costly manufacturing problems. 'Black Spots' on tablets resulting in high numbers of rejected tablets, increased wear of punch guides and tightening of upper punches can result in excessive machine down time and high maintenance costs.

Sealed grove punch die sets are designed to prevent guide way and tablet contamination during the tablet compression process, a vast improvement over traditional dust caps used in the pharmaceutical, confectionery and allied industries.
